Kod | Referans | Gövde | A | B | C | D | E | L | H |
06010301 | POLIPROFILE3+M2 | MORSE 2 DIN 228 | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010302 | POLIPROFILE3+M3 | MORSE 3 DIN 228 | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010303 | POLIPROFILE3+C16 | Ø16 mm | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010304 | POLIPROFILE3+C20 | Ø20 mm | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010305 | POLIPROFILE3+C25 | Ø25 mm | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010306 | POLIPROFILE3+W20 | Weldon 20 DIN 1835B | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010307 | POLIPROFILE3+W25 | Weldon 25 DIN 1835B | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010308 | POLIPROFILE3+VDI20 | VDI20 DIN 69880 | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
06010309 | POLIPROFILE3+VDI30 | VDI30 DIN 69880 | 55 | 22 | 80 | 68 | 22 | <10 | <14 |
